Xerox PHASER 7500 Service Manual

3-214 Phaser 7500 Printer Service Manual
Error Messages and Codes
L/H Cover Interlock Open
The L/H Cover is open.
Applicable Chain-Link Code
• 077-301: Left Hand Cover Open
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
1. Perform the following steps:
• Check the L/H Cover Unit for damage or mismatch.
• Perform the Interlocks test in Diagnostics.
• Check the connection between the L/H Cover Interlock Switch J100 and
the Motor Drive PWB J521 for open circuit, short circuit, and poor contact.
2. If no problems are found, replace the following parts in sequence:
• Motor Drive PWB (REP 18.13, page 8-204)
• MCU PWB (REP 18.12, page 8-202)
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ MCU PWB, PL18.3.6
■ Motor Drive PWB, PL18.3.7

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
