Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 2-57
Theory of Operation
Drive Assembly
This section contains illustrations for the mechanical components of the Drive
Assembly.
Main Drive Motor Assembly (PL3.2.3)
Drum/ Deve Drive Motor (K) (PL3.3.3)
s7500-386
Bracket Assembly
Registration Clutch
Registration
Roller
Main Drive Motor
Gear(40T)
Gear(23T)
Back Up Roll
Drive Roll
IBT Belt Unit
Take Away Clutch
Take Away Roller
s7500-387
Magnet Roller
Auger
Drum/Developer
Drive Motor (K)
Drive Assembly
Auger
Drum
Drum (K)
Developer Housing
Assembly (K)

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
