Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 6-7
Adjustments and Calibrations
RegiCon Check
The RegiCon Check allows the user to check whether the detectors are operating
normally by checking the function of the Registration Control Sensor (MOB Sensor
[MOB ADC Assembly]).
The RegiCon Check measures the amounts of regi shift in the lateral/process
directions and then displays those amounts together with the results.
Caution
The functions of the menus described here have great effect on the print
quality and operation of the machine. In addition, they include the
adjustment functions used at shipment. DO NOT change the settings unless
specified otherwise in this manual.
Procedure
1. Enter Service Diagnostics (page 4-9).
2. Scroll down the menu and select Adjustments/ Calibrations. Press OK.
3. Select RegiCon Check and press OK.
4. The printer starts processing with a Starting Measurement... Reading data...
message appears.
5. When the process is complete, the RegiCon Check result is displayed.
•Result is OK/ NG

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
