Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 10-45
Plug/Jack and Wiring Diagrams
Print Engine - Interlock Switches, Agitator Motor, Fuser Fan
Motor Driver Board
s7500-493
M
P/J215
Agitator
Motor
4
3
2
P/J523
P/J517
1
2
3
1
B2
B1
A1
A2
4
AGI_MOT_B
AGI_MOT_A
AGI_MOT_/B
AGI_MOT_/A
P/J521
1
2
4
3
+24VDC
I/L_24V
ESS
I/L_ESS
P/J237
FUSER_FAN_ON
/FAN_FAIL
GND
N.C.
4
3
2
1
1
2
3
4
Fuser Fan
LH Cover
Interlock Switch
B2
B1
A1
A2
P/J519
1
2
4
3
+24VDC
I/L_24V
ESS
I/L_ESS
Front Cover
Interlock Switch
+24VDC
+24VDC

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
