Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 3-247
Error Messages and Codes
Waste Toner Bottle Near Full
The Waste Toner Bottle Full Sensor detected Near Full state.
Applicable Chain-Link Code
• 091-400: Waste Toner Bottle Near Full
Initial Actions
• Check the Waste Cartridge life.
• If the problem persists, follow the procedure below.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Waste Toner Bottle Full
Sensor, PL8.2.3
■ Waste Cartridge, PL8.2.19
■ MCU PWB, PL18.3.6
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Replace the Waste Cartridge as
required (REP 1.3, page 8-12).
Does that fix the problem?
Troubleshooting
complete.
Go to step 2.
2 Perform the Toner Waste
Cartridge Sensors test in
Diagnostics.
Use a sheet of paper, etc. to block/
clear the light path to the Waste
Toner Bottle Position Sensor.
Does the display change between
High/ Low?
Replace the
MCU PWB
(REP 18.12,
page 8-202).
Go to “General
Sensor Failure”
on page 3-28
to check the
Waste Toner
Bottle Position
Sensor.

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
