Xerox PHASER 7500 - Maintenance Items and Consumables; REP 1.1 Toner Cartridge (Y;M;C;K)

Phaser 7500 Printer Service Manual 8-9
Service Parts Disassembly
Maintenance Items and Consumables
Maintenance and Consumable items include the Toner Cartridges, Imaging Units,
Waste Cartridge, Fuser Assembly, Transfer Roller, Transfer Belt, and Feed Rollers.
REP 1.1 Toner Cartridge (Y/M/C/K)
PL5.1.1 - PL5.1.4
1. Open the Front Door.
2. Pull the Toner Cartridge toward you to remove it.
s7500-450
