Xerox PHASER 7500 Service Manual

2-66 Phaser 7500 Printer Service Manual
Theory of Operation
Operating Mode
Three operating modes are available in the Phaser 7500.
Ready Mode
The Ready mode operates states such as running or recording, etc.
Standby Mode
It is possible to enter the Standby mode within 25 seconds after power Off then
On or from the Sleep Mode.
Item Status
Processor
Image Processor Board Full Power
UI LCD Normal display
LED On
IOT Fusing system (Fuser Assembly) Maintains the operating
temperature
Recording system (Transfer/
Developer)
In operation
MCU PWB Full power
Item Status
Processor
Image Processor Board Full Power
UI LCD Normal display
LED On
IOT Fusing system (Fuser Assembly) Maintains the operating
temperature
Recording system (Transfer/
Developer)
Paused
MCU PWB Full power

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
