Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 3-103
Error Messages and Codes
Motor Drive PWB F1 Blows
Fuse 1 on the Motor Drive PWB has blown.
Note
Remove the cause of Fuse failure before replacing the Motor Drive PWB.
Applicable Chain-Link Code
• 041-344: PWBA Motor Drive F1 Fuse Break Fail
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
1. Check the following parts circuits for overcurrent and overvoltage, grounded
wires, and then replace the faulty parts or repair the circuits, and replace the
Fuse.
•Regi Clutch (REP 15.3, page 8-175)
•Fuser Fan (REP 4.1, page 8-38)
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser Fan, PL4.1.7
■ Regi Clutch, PL15.2.4
■ Fuse

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
