10-14 Phaser 7500 Printer Service Manual
Plug/Jack and Wiring Diagrams
3 Tray Unit (Optional) Plug/Jack Designators
3 Tray Unit Plug/Jack Designators
P/J Map Coordinates Remarks
101 15 D-334 Connection between the Tray 2 Paper Size Sensor
(PL10.1.8) and the Harness Assy (Sensor2)
(PL10.9.6)
102 15 D-335 Connection between the Tray 3 Paper Size Sensor
(PL10.1.9) and the Harness Assy (Sensor2)
(PL10.9.6)
103 15 D-336 Connection between the Tray 4 Paper Size Sensor
(PL10.1.10) and the Harness Assy (Sensor2)
(PL10.9.6)
104 15 J-337 Connection between the Tray Module L/H Cover
Switch (PL10.11.2) and the Wire Harness (TM SW)
(PL10.11.3)
106 15 G-334 Connection between the Tray 2 No Paper Sensor
(PL10.3.6) and the Harness Assy (Sensor1)
(PL10.3.21)
107 15 F-334 Connection between the Tray 2 Nudger Level
Sensor (PL10.3.6) and the Harness Assy (Sensor1)
(PL10.3.21)
108 15 H-334 Connection between the Tray 2 Feed Out Sensor
(PL10.11.11) and the Harness Assy (Sensor2)
(PL10.9.6)
110 15 G-335 Connection between the Tray 3 No Paper Sensor
(PL10.5.6) and the Harness Assy (Sensor1)
(PL10.5.21)
111 15 F-335 Connection between the Tray 3 Nudger Level
Sensor (PL10.5.6) and the Harness Assy (Sensor1)
(PL10.5.21)
112 15 H-335 Connection between the Tray 3 Feed Out Sensor
(PL10.11.6) and the Harness Assy (FO) (PL10.11.9)
114 15 G-336 Connection between the Tray 4 No Paper Sensor
(PL10.7.6) and the Harness Assy (Sensor1)
(PL10.7.21)
115 15 F-336 Connection between the Tray 4 Nudger Level
Sensor (PL10.7.6) and the Harness Assy (Sensor1)
(PL10.7.21)
116 15 H-336 Connection between the Tray 4 Feed Out Sensor
(PL10.11.6) and the Harness Assy (FO) (PL10.11.9)
221 15 H-341 Connection between the Tray 2 Feed/Lift Up
Motor (PL10.3.3) and the Harness Assy (Motor1)
(PL10.3.20)
222 15 H-342 Connection between the Tray 3 Feed/Lift Up
Motor (PL10.5.3) and the Harness Assy (Motor1)
(PL10.5.20)
To Next Page
