Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 10-15
Plug/Jack and Wiring Diagrams
223 15 H-344 Connection between the Tray 4 Feed/Lift Up
Motor (PL10.7.3) and the Harness Assy (Motor1)
(PL10.7.20)
224 15 D-337 Connection between the TM Takeaway Motor
(PL10.9.5) and the Harness Assy (Motor2)
(PL10.9.7)
541 15 A-341 Connection between the Tray Module PWB
(PL10.9.1) and the Harness Assy (I/F) (PL10.9.8)
548 15 B-343 Connection between the Tray Module PWB
(PL10.9.1) and the Harness Assy (Sensor2)
(PL10.9.6)
549 15 A-342 Connection between the Tray Module PWB
(PL10.9.1) and the Harness Assy (Sensor2)
(PL10.9.6)
550 15 B-341 Connection between the Tray Module PWB
(PL10.9.1) and the Harness Assy (Motor2)
(PL10.9.7)
551 15 C-342 Connection between the Tray Module PWB
(PL10.9.1) and the Harness Assy (Motor2)
(PL10.9.7)
661 15 I-341 Connection between the Harness Assy (Motor1)
(PL10.3.20) and the Harness Assy (Motor2)
(PL10.9.7)
662 15 I-342 Connection between the Harness Assy (Motor1)
(PL10.5.20) and the Harness Assy (Motor2)
(PL10.9.7)
663 15 I-344 Connection between the Harness Assy (Motor1)
(PL10.7.20) and the Harness Assy (Motor2)
(PL10.9.7)
668 15 I-344 Connection between the Wire Harness (TM SW)
(PL10.11.3) and the Harness Assy (Sensor2)
(PL10.9.6)
669 15 I-341 Connection between the Harness Assy (Sensor1)
(PL10.3.21) and the Harness Assy (Sensor2)
(PL10.9.6)
671 15 I-342 Connection between the Harness Assy (Sensor1)
(PL10.5.21) and the Harness Assy (Sensor2)
(PL10.9.6)
672 15 I-341 Connection between the Harness Assy (FO)
(PL10.11.9) and the Harness Assy (Sensor2)
(PL10.9.6)
673 15 I-344 Connection between the Harness Assy (Sensor1)
(PL10.7.21) and the Harness Assy (Sensor2)
(PL10.9.6)
674 15 I-343 Connection between the Harness Assy (FO)
(PL10.11.9) and the Harness Assy (Sensor2)
(PL10.9.6)
3 Tray Unit Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
