Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 3-153
Error Messages and Codes
LPH Download Data Fail M
DELSOL register data error during the LPH batch download complete verification,
download error, or connector error. When the DELSOL register value is incorrect, it
is a register data error. When the download process has failed, it is a download
error. It may also be a connector error because the batch download check control
does not cause Act error or Write error to occur.
Note
If this error occurs, it is possible that the process have not been performed
correctly because of other LPH Fail. If other LPH Fail had occurred, solving that
other LPH Fail has a higher priority.
Applicable Chain-Link Code
• 061-355: LPH Download Data Fail M
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ LPH Unit (M), PL2.1.2
■ LPH Cable Assy, PL2.2.1
■ LPH Rear PWB (M), PL2.2.5
■ MCU PWB, PL18.3.6
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the Fault History.
Have multiple errors occurred?
Replace the
MCU PWB
(REP 18.12,
page 8-202).
Go to step 2.

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
