Xerox PHASER 7500 - Tray 1 Feed; Nudger Motor (PL13.2.18)

To Next Page

To Previous Page

2-62 Phaser 7500 Printer Service Manual

Theory of Operation

Tray 1 Feed/ Nudger Motor (PL13.2.18)

Gear (31T/15T)

s7500-415

Gear (29T/19T)

Gear (30T)

Tray 1 (MPT)

Feed/Nudger Motor

Gear (27T)

Gear (20T)

Gear (19T)

Nudger Roller

Feed Roller

Nudger Cam
