3-92 Phaser 7500 Printer Service Manual
Error Messages and Codes
SMH Size Mismatch
The paper size in Tray 1 and the paper size specified for printing are
different.
Applicable Chain-Link Code
• 024-958: SMH Size mismatch
Initial Actions
• Inspect the tray to ensure that it is free of obstructions, is loaded with
supported paper, and the Guides are adjusted correctly.
• If the problem persists, follow the procedure below.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ “Tray 1 (MPT)” on page 10-52
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Is the A/D Value Range correct for
the size of paper loaded?
Does the Sensor change value?
Replace the
MCU PWB
(REP 18.12,
page 8-202).
Troubleshoot
and repair the
Sensor or
wiring harness.
Refer to the
Tray 1 (MPT)
wiring
diagram.

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
