3-120 Phaser 7500 Printer Service Manual
Error Messages and Codes
Process 2 Fan Fail
The Process 2 Fan error was detected.
Applicable Chain-Link Code
• 042-336: Process 2 Fan Fail
Initial Actions
• Rotate the Fan manually to check for binding.
• Power cycle the printer.
• If the problem persists, follow the procedure below.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Process 2 Fan Assy, PL4.2.13
■ MCU PWB, PL18.3.6
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the Fault History.
Has error 041-330 MCU PWB F7
Blows occurred?
Is F7 on the MCU PWB open?
Note: The condition that caused
F7 to open must be corrected
before replacing the MCU PWB.
Go to step 5. Go to step 2.
2 Perform the Process 2 Fan Motor
test in Diagnostics.
Is the Process 2 fan rotating?
Go to step 5. Go to step 3.
3 Turn Off the power.
Reseat P/ J 238 and P 416.
Turn On the power.
Repeat the Process 2 Fan Motor
test in Diagnostics.
Is the Process 2 Fan now rotating?
Go to step 4. Go to step 5.
4 Does the error appear now when
making a print?
Go to step 5. Troubleshooting
complete.

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
