Single Tray Module (STM) (Optional) Plug/Jack Designators
Single Tray Module (STM) Plug/Jack Designators
P/J Map Coordinates Remarks
101 14 D-324 Connection between the Tray 3 Paper Size Sensor
(PL11.1.14) and the Harness Assy (Sensor2-STM)
(PL11.5.5)
104 14 F-325 Connection between the STM L/H Cover Switch
(PL11.6.5) and the Harness Assy (Sensor2-STM)
(PL11.5.5)
106 14 G-324 Connection between the Tray 3 No Paper Sensor
and the Harness Assy (Sensor1-STM)
107 14 G-324 Connection between the Tray 3 Nudger Level
Sensor and the Harness Assy (Sensor1-STM)
108 14 H-324 Connection between the Tray 2 Feed Out Sensor
(PL11.6.3) and the Harness Assy (Sensor2-STM)
(PL11.5.5)
221 14 E-325 Connection between the Tray 2 Feed/Lift Up
Motor and the Harness Assy (Motor1-STM)
224 14 D-325 Connection between the STM T/A Motor Assy
(PL11.5.2) and the Harness Assy (Motor2-STM)
(PL11.5.6)
541 14 C-319 Connection between the STM PWB (PL11.5.4) and
the Harness Assy (IF-STM) (PL11.5.7)
548 14 A-319 Connection between the STM PWB (PL11.5.4) and
the Harness Assy (Sensor2-STM) (PL11.5.5)
550 14 B-320 Connection between the STM PWB (PL11.5.4) and
the Harness Assy (Motor2-STM) (PL11.5.6)
551 14 C-320 Connection between the STM PWB (PL11.5.4) and
the Harness Assy (Motor2-STM) (PL11.5.6)
661 14 F-325 Connection between the Harness Assy (Motor1-
STM) and the Harness Assy (Motor2-STM)
(PL11.5.6)
669 14 F-325 Connection between the Harness Assy (Sensor1-
STM) and the Harness Assy (Sensor2-STM)
(PL11.5.5)
