Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 10-11
Plug/Jack and Wiring Diagrams
633 1 G-108 Connection between the ATC PWB (PL5.2.18) and
the Wire Harness (Main Front) (PL18.4.5)
700 1 I-105 Connection between the Console Harness
(PL19.2.14) and the Wire Harness (UI) (PL18.1.8)
701 1 F-104 Connection between the Control Panel
(PL19.2.13) and the Console Harness (PL19.2.14)
701 6 F-109 Connection between the Control Panel and UI.
702 3 I-107 Connection between the Image Processor Board
and Back Plane PWB.
800 5 D-139 Connection between the TM Relay PWB
(PL18.3.11) and the Tray Module (Option)
801 5 D-139 Connection between the TM Relay PWB
(PL18.3.11) and the Wire Harness (Tray)
(PL18.3.13)
3001 5 E-135 Connection between the Wire Harness (ESS2)
(PL18.3.12) and the Wire Harness (ESS1)
(PL18.2.9)
5111 12 C-223 Connection between the Exit Motor (PL17.1.15)
and the Wire Harness (Main LH) (PL18.4.2)
5112 N/A N/A Connection between the Exit Sensor Full Sensor
and the Wire Harness (Main LH) (PL18.4.2)
5161 9 A-181 Connection between the Thermo Sensor
(PL18.1.14) and the Wire Harness (Main RH)
(PL18.4.3)
7003 5 D-135 Connection between the Wire Harness (BP)
(PL18.3.3) and the Wire Harness (UI) (PL18.1.8)
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
