10-10 Phaser 7500 Printer Service Manual
Plug/Jack and Wiring Diagrams
553 8 E-167 Connection between the LPH Rear PWB (Y)
(PL2.2.5) and the Wire Harness (Main RH)
(PL18.4.3)
554 2 I-117 Connection between the MCU PWB (PL18.3.6)
and the LPH Cable Assy (PL2.2.1)
555 2 J-117 Connection between the MCU PWB (PL18.3.6)
and the LPH Cable Assy (PL2.2.1)
556 2 I-118 Connection between the MCU PWB (PL18.3.6)
and the LPH Cable Assy (PL2.2.1)
557 2 J-118 Connection between the MCU PWB (PL18.3.6)
and the LPH Cable Assy (PL2.2.1)
558 8 E-168 Connection between the LPH Rear PWB (Y)
(PL2.2.5) and the LPH Cable Assy (PL2.2.1)
559 8 F-168 Connection between the LPH Rear PWB (M)
(PL2.2.5) and the LPH Cable Assy (PL2.2.1)
560 8 G-168 Connection between the LPH Rear PWB (C)
(PL2.2.5) and the LPH Cable Assy (PL2.2.1)
561 8 I-169 Connection between the LPH Rear PWB (K)
(PL2.2.5) and the LPH Cable Assy (PL2.2.1)
600 12 I-230 Connection between the Fuser Assy (PL7.1.1) and
the Wire Harness (Drawer) (PL18.4.1)
610 1 C-106 Connection between the MOB ADC Assy
(PL18.1.4) and the Wire Harness (Main Top)
(PL18.4.4)
611 10 F-195 Connection between the Wire Harness (Tray 2
Feeder) (PL9.4.20) and the Wire Harness (Main
Front) (PL18.4.5)
612 11 C-211 Connection between the Wire Harness (LH Cover)
(PL14.4.17) and the Wire Harness (Main LH)
(PL18.4.2)
614 9 H-184 Connection between the Wire Harness (Toner
Bottle Full) (PL8.2.18) and the Wire Harness (Main
RH) (PL18.4.3)
615 1 J-107 Connection between the Wire Harness (Main RH)
(PL18.4.3) and the Main Power Switch Chassis
Assy (PL18.1.1)
616 10 B-200 Connection between the Wire Harness (MPT)
(PL13.4.2) and the Wire Harness (Main LH)
(PL18.4.2)
617 10 B-201 Connection between the Wire Harness (MSI Tray)
(PL13.5.9) and the Wire Harness (MPT) (PL13.4.2)
619 5 J-141 Connection between the IBT 1 & IBT 2 Fans and
the MCU
632 11 E-212 Connection between the Wire Harness (Reg)
(PL15.2.13) and the Wire Harness (Main LH)
(PL18.4.2)
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
