Phaser 7500 Printer Service Manual 10-9
Plug/Jack and Wiring Diagrams
516 2 E-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main RH)
(PL18.4.3)
517 2 D-127 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main LH)
(PL18.4.2)
518 2 F-128 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main RH)
(PL18.4.3)
519 2 E-127 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main RH)
(PL18.4.3)
520 2 F-127 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main RH) to the
LVPS (PL18.4.3)
521 2 E-127 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main LH)
(PL18.4.2)
522 2 D-127 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main Front)
(PL18.4.5)
523 2 C-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main RH)
(PL18.4.3)
524 2 D-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main LH)
(PL18.4.2)
525 2 E-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main LH)
(PL18.4.2)
526 2 E-127 Connection between the Motor Drive PWB
(PL18.3.7) and
the Wire Harness (Main Front) (PL18.4.5)
530 9 G-182 Connection between the Main LVPS (PL18.1.11)
and
the Wire Harness (Main RH) (PL18.4.3)
550 8 H-169 Connection between the LPH Rear PWB (K)
(PL2.2.5) and the Wire Harness (Main RH)
(PL18.4.3)
550 9 G-183 Connection between the Main LVPS (PL18.1.11)
and the LV Fan (PL18.1.13)
551 8 G-168 Connection between the LPH Rear PWB (C)
(PL2.2.5) and the Wire Harness (Main RH)
(PL18.4.3)
552 8 F-168 Connection between the LPH Rear PWB (M)
(PL2.2.5) and the Wire Harness (Main RH)
(PL18.4.3)
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
