10-8 Phaser 7500 Printer Service Manual
Plug/Jack and Wiring Diagrams
451 5 E-137 Connection between the MCU PWB (PL18.3.6)
and the BP PWB (PL18.3.2)
452 2 B-127 Connection between the MD PWB (PL18.3.7) and
the MCU PWB (PL18.3.6)
460 4 F-104 Connection between the Back Plane PWB and the
MCU PWB.
460 7 E-152 Connection between the HVPS (1st/2nd/DTC)
(PL6.2.9) and the Wire Harness (Main RH)
(PL18.4.3)
461 9 E-184 Connection between the HVPS (Deve/BCR)
(PL18.1.7) and the Wire Harness (Main RH)
(PL18.4.3)
501 9 G-183 Connection between the Main LVPS (PL18.1.11)
and the Wire Harness (ESS1) (PL18.2.9)
502 2 A-128 Connection between the MD PWB (PL18.3.7) and
the Wire Harness (Main RH) (PL18.4.3)
503 9 G-183 Connection between the Main LVPS (PL18.1.11)
and the Wire Harness (Main RH) (PL18.4.3)
504 2 F-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main LH)
(PL18.4.2)
505 2 F-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main LH)
(PL18.4.2)
506 2 B-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main RH)
(PL18.4.3)
507 2 B-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main RH)
(PL18.4.3)
508 2 A-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main RH)
(PL18.4.3)
509 2 A-127 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Tray)
(PL18.3.13)
510 9 G-182 Connection between the Main LVPS (PL18.1.11)
and the Wire Harness (Main RH) (PL18.4.3)
513 2 F-128 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main LH)
(PL18.4.2)
515 2 C-129 Connection between the Motor Drive PWB
(PL18.3.7) and the Wire Harness (Main LH)
(PL18.4.2)
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
