Phaser 7500 Printer Service Manual 10-7
Plug/Jack and Wiring Diagrams
268 10 D-195 Connection between the Tray 1 Feed/Lift Up
Motor (PL9.4.3) and the Wire Harness (Feeder)
(PL9.4.20)
269 10 C-201 Connection between the MPT Feed/Nudger Motor
(PL13.2.18) and the Wire Harness (MSI)
(PL13.4.2)
272 1 B-106 Connection between the Front Cover Interlock
Switch (PL18.1.9) and the Wire Harness (Main
Top) (PL18.4.4)
273 7 C-153 Connection between the Auger Lock Sensor
(PL8.2.16) and the Wire Harness (Main RH)
(PL18.4.3)
280 11 E-214 Connection between the 2nd BTR Contact Retract
Motor (PL14.4.10) and the Wire Harness (LH
Cover) (PL14.4.17)
300 5 E-136 Connection between the ESS PWB (PL35.1.3) and
the Wire Harness (ESS2) (PL18.3.12)
306 4 F-104 Connection between the BP PWB (PL18.3.2) and
the Wire Harness (BP) (PL18.3.3)
306 5 D-136 Connection between the BP PWB (PL18.3.2) and
the Wire Harness (BP) (PL18.3.3)
335 4 E-108 Connection betweeen the Back Plane PWB and
the Image Processor Board.
335 5 E-138 Connection between the Image Processor Board
(PL35.1.3) and the Back Plane PWB (PL18.3.2)
401 2 I-120 Connection between the MCU PWB (PL18.3.6)
and the Wire Harness (Main RH) (PL18.4.3)
401 6 A-109 Connection between the Control Panel and the
Wire Harness to the Back Plane PWB.
411 2 H-116 Connection between the MCU PWB (PL18.3.6)
and the Wire Harness (Main Top) (PL18.4.4)
412 2 J-120 Connection between the MCU PWB (PL18.3.6)
and the Wire Harness (Main RH) (PL18.4.3)
414 2 J-120 Connection between the MCU PWB (PL18.3.6)
and the Wire Harness (Main RH) (PL18.4.3)
415 2 I-116 Connection between the MCU PWB (PL18.3.6)
and the Wire Harness (Main Top) (PL18.4.4)
416 2 G-116 Connection between the MCU PWB (PL18.3.6)
and the Wire Harness (Main Top) (PL18.4.4)
417 2 J-119 Connection between the MCU PWB (PL18.3.6)
and the Wire Harness (Main RH) (PL18.4.3)
431 2 J-116 Connection between the MCU PWB (PL18.3.6)
and the Wire Harness (Drawer) (PL18.4.1)
451 2 G-118 Connection between the MCU PWB (PL18.3.6)
and the BP PWB (PL18.3.2)
Print Engine Plug/Jack Designators (Continued)
