10-6 Phaser 7500 Printer Service Manual
Plug/Jack and Wiring Diagrams
231 5 I-139 Connection between the Drive Fan (PL18.3.17)
and the Wire Harness (Main RH) (PL18.4.3)
234 N/A N/A Connection between the Bottom Fan and the
Wire Harness (Main RH) (PL18.4.3)
235 7 B-154 Connection between the HV Fan (PL4.2.4) and
the Wire Harness (Main RH) (PL18.4.3)
238 N/A N/A Connection between the P2 Fan and MCU Board
240 7 G-154 Connection between the Drum/Deve Drive Motor
(K) (PL3.3.3) and the Wire Harness (Main RH)
(PL18.4.3)
241 7 G-155 Connection between the Drum/Deve Drive Motor
(K) (PL3.3.3) and the Wire Harness (Main RH)
(PL18.4.3)
242 7 I-153 Connection between the Fuser Drive Motor
(PL3.1.11) and the Wire Harness (Main LH)
(PL18.4.2)
243 7 I-152 Connection between the Fuser Drive Motor
(PL3.1.11) and the Wire Harness (Main LH)
(PL18.4.2)
244 7 I-154 Connection between the Main Drive Motor Assy
(PL3.2.3) and the Wire Harness (Main LH)
(PL18.4.2)
245 7 I-154 Connection between the Main Drive Motor Assy
(PL3.2.3) and the Wire Harness (Main LH)
(PL18.4.2)
246 7 E-153 Connection between the Drum/Deve Drive Motor
(Y, M, C) (PL3.3.5) and the Wire Harness (Main
RH) (PL18.4.3)
247 7 E-153 Connection between the Drum/Deve Drive Motor
(Y, M, C) (PL3.3.5) and the Wire Harness (Main
RH) (PL18.4.3)
248 7 C-153 Connection between the IBT Drive Motor
(PL3.3.4) and the Wire Harness (Main RH)
(PL18.4.3)
249 7 C-153 Connection between the IBT Drive Motor
(PL3.3.4) and the Wire Harness (Main RH)
(PL18.4.3)
250 7 G-153 Connection between the 1st BTR Contact Retract
Clutch (PL3.2.12) and the Wire Harness (Main RH)
(PL18.4.3)
260 11 F-212 Connection between the Regi Clutch (PL15.2.4)
and the Wire Harness (Reg) (PL15.2.13)
261 7 I-156 Connection between the Takeaway Clutch
(PL15.1.1) and the Wire Harness (Main RH)
(PL18.4.3)
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
To Next Page
