Phaser 7500 Printer Service Manual 10-5
Plug/Jack and Wiring Diagrams
181 11 G-214 Connection between the 2nd BTR Contact Retract
Sensor (PL14.4.7) and the Wire Harness (LH
Cover) (PL14.4.17)
182 1 E-112 Internal connection of the MOB ADC Assy
(PL18.1.4) (IBT Belt Home Position Sensor)
183 10 C-201 Connection between the MPT Nudger Position
Sensor (PL13.2.20) and the Wire Harness (MSI)
(PL13.4.2)
190 N/A N/A Internal connection of the Fuser Assembly
(PL7.1.1) NC Sensor
191 N/A N/A Internal connection of the Fuser Assembly
(PL7.1.1) STS Sensor
192 12 H-215 Internal connection of the Fuser Assy (PL7.1.1)
(Fuser Exit Sensor)
201 3 D-108 Memory slot
202 3 E-108 Memory slot
206 3 C-107 USB connection
210 1 G-106 Connection between the Erase Lamp Unit (Y)
(PL8.1.5) and the Wire Harness (Main Top)
(PL18.4.4)
211 1 F-106 Connection between the Erase Lamp Unit (M)
(PL8.1.5) and the Wire Harness (Main Top)
(PL18.4.4)
212 1 E-106 Connection between the Erase Lamp Unit (C)
(PL8.1.5) and the Wire Harness (Main Top)
(PL18.4.4)
213 1 D-106 Connection between the Erase Lamp Unit (K)
(PL8.1.5) and the Wire Harness (Main Top)
(PL18.4.4)
215 7 C-153 Connection between the Agitator Motor (PL8.2.7)
and the Wire Harness (Main RH) (PL18.4.3)
220 8 D-165 Connection between the Toner Dispense Motor
(Y) (PL5.1.7) and the Wire Harness (Main RH)
(PL18.4.3)
221 8 E-166 Connection between the Toner Dispense Motor
(M) (PL5.1.7) and the Wire Harness (Main RH)
(PL18.4.3)
222 8 F-165 Connection between the Toner Dispense Motor
(C) (PL5.1.7) and the Wire Harness (Main RH)
(PL18.4.3)
223 8 G-166 Connection between the Toner Dispense Motor
(K) (PL5.1.7) and the Wire Harness (Main RH)
(PL18.4.3)
230 5 H-138 Connection between the Fuser Fan (PL4.1.7) and
the Wire Harness (Main LH) (PL18.4.2)
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
To Next Page
