10-4 Phaser 7500 Printer Service Manual
Plug/Jack and Wiring Diagrams
125 1 G-108 Connection between the ATC Sensor Assy (M)
(PL5.2.4) and the ATC PWB (PL5.2.18)
126 1 F-108 Connection between the ATC Sensor Assy (C)
(PL5.2.4) and the ATC PWB (PL5.2.18)
127 1 E-108 Connection between the ATC Sensor Assy (K)
(PL5.2.4) and the ATC PWB (PL5.2.18)
130 9 F-183 Connection between the NOHAD Thermistor Assy
(PL5.2.11) and the Wire Harness (Main RH)
(PL18.4.3)
144 7 G-153 Connection between the 1st BTR Contact Retract
Sensor (PL3.2.17) and the Wire Harness (Main RH)
(PL18.4.3)
150 1 D-112 Internal connection of the MOB ADC Assy
(PL18.1.4) (MOB Sensor In)
151 1 A-114 Internal connection of the MOB ADC Assy
(PL18.1.4) (MOB Sensor Out)
153 1 B-113 Internal connection of the MOB ADC Assy
(PL18.1.4) (ADC Sensor Assy)
154 1 E-112 Internal connection of the MOB ADC Assy
(PL18.1.4) (Environment Sensor)
160 11 H-213 Connection between the Regi Sensor (PL15.2.10)
and the Wire Harness (Reg) (PL15.2.13)
161 11 I-213 Connection between the Transparency Sensor
(PL15.2.7) and the Wire Harness (Reg) (PL15.2.13)
172 10 G-203 Connection between the MPT No Paper Sensor
(PL13.4.17) and the Wire Harness (MSI)
(PL13.4.2)
173 10 F-203 Connection between the MPT Paper Size Sensor
(PL13.5.4) and the Wire Harness (MSI Tray)
(PL13.5.9)
174 8 F-169 Connection between the Tray 1 Paper Size Sensor
(PL9.1.6) and the Wire Harness (Main RH)
(PL18.4.3)
177 10 F-195 Connection between the Tray 1 Nudger Level
Sensor (PL9.4.6) and the Wire Harness (Feeder)
(PL9.4.20)
178 10 G-195 Connection between the Tray 1 No Paper Sensor
(PL9.4.6) and the Wire Harness (Feeder)
(PL9.4.20)
179 10 G-202 Connection between the MPT Feed Out Sensor
(PL13.4.16) and the Wire Harness (MSI)
(PL13.4.2)
180 11 E-214 Connection between the POB Sensor (PL14.4.16)
and the Wire Harness (LH Cover) (PL14.4.17)
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
To Next Page
