Phaser 7500 Printer Service Manual 10-3
Plug/Jack and Wiring Diagrams
59 1 H-113 Internal connection of the Main Power Switch
Chassis Assy (PL18.1.1)
60 1 I-113 Internal connection of the Main Power Switch
Chassis Assy (PL18.1.1)
61 1 I-113 Internal connection of the Main Power Switch
Chassis Assy (PL18.1.1)
100 5 J-136 Connection between the L/H Cover Interlock
Switch (PL14.1.3) and the Wire Harness (Main LH)
(PL18.4.2)
101 1 I-106 Connection between the Front Cover Interlock
Switch (PL18.1.9) and the Wire Harness (Main RH)
(PL18.4.3)
107 3 C-110 Ethernet connection
110 9 F-184 Connection between the Waste Toner Bottle Full
Sensor (PL8.2.3) and the Wire Harness (Toner Full)
(PL8.2.18)
111 9 G-184 Connection between the Waste Toner Bottle
Position Sensor (PL8.2.4) and the Wire Harness
(Main RH) (PL18.4.3)
112 1 H-106 Connection between the Drum CRUM Coupler
Assy (Y) (PL8.1.3) and the Wire Harness (Main
Front) (PL18.4.5)
113 1 G-106 Connection between the Drum CRUM Coupler
Assy (M) (PL8.1.3) and the Wire Harness (Main
Front) (PL18.4.5)
114 1 E-106 Connection between the Drum CRUM Coupler
Assy (C) (PL8.1.3) and the Wire Harness (Main
Front) (PL18.4.5)
115 1 D-106 Connection between the Drum CRUM Coupler
Assy (K) (PL8.1.3) and the Wire Harness (Main
Front) (PL18.4.5)
120 8 D-164 Connection between the Toner CRUM [Toner
Cartridge (Y)] (PL5.1.4) and the Wire Harness
(Main Top) (PL18.4.4)
121 8 E-165 Connection between the Toner CRUM [Toner
Cartridge (M)] (PL5.1.3) and the Wire Harness
(Main Top) (PL18.4.4)
122 8 F-165 Connection between the Toner CRUM [Toner
Cartridge (C)] (PL5.1.2) and the Wire Harness
(Main Top) (PL18.4.4)
123 8 G-165 Connection between the Toner CRUM [Toner
Cartridge (K)] (PL5.1.1) and the Wire Harness
(Main Top) (PL18.4.4)
124 1 H-108 Connection between the ATC Sensor Assy (Y)
(PL5.2.4) and the ATC PWB (PL5.2.18)
Print Engine Plug/Jack Designators (Continued)
P/J Map Coordinates Remarks
To Next Page
