Xerox PHASER 7500 Service Manual

2-54 Phaser 7500 Printer Service Manual
Theory of Operation
Tray 5 Feed Out Sensor (PL10.11.6)
Tray 5 Feed Out Sensor detects whether paper was fed from Tray 5.
Note
No paper: Sensor blocked
Tray Module L/H Cover Switch (PL10.11.2)
The Tray Module L/H Cover Switch detects the Open/ Close state of Left Hand
Cover of the 3 Tray Cabinet.
Tray Module PWB (PL10.9.1)
The Tray Module PWB controls all 3 Tray Cabinet components.
Paper Feed Components
s7500-384
Tray Feed / Lift Up Motor
Tray No Paper Sensor
Tray Nudger Level Sensor

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
