3-128 Phaser 7500 Printer Service Manual

Error Messages and Codes

5 Check whether the F7 on the MCU

PWB has melted down.

Is it normal and has not melted

down?

Troubleshooting

complete.

Repair the

section that

has melted.

Troubleshooting Procedure (Continued)

Step Actions and Questions Yes No
