3-200 Phaser 7500 Printer Service Manual
Error Messages and Codes
6 Check the Tray Lift Up Gear for
damage or the Tray Lift Up
mechanism for mechanical load.
Is it normal, without damage or
loading?
Replace the
following parts
in sequence:
When 3TM is
connected:
Tray Module
PWB (REP 10.9,
page 8-97)
When STM is
connected:
■ STM PWB
(REP 11.10,
page 8-120)
■ TM Relay
PWB (REP
18.14,
page 8-205)
■ Motor Drive
PWB (REP
18.10,
page 8-197)
■ MCU PWB
(REP 18.12,
page 8-202)
Repair the
sections that
have damage or
loading.
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
