Phaser 7500 Printer Service Manual 3-233
Error Messages and Codes
5 Check the Cyan Imaging Unit for
contamination, scratches, or
distortion.
Is the Imaging Unit normal?
Go to step 6. Replace the
Cyan Imaging
Unit (REP 1.2,
page 8-10).
6 Replace the MOB ADC Assembly
(REP 18.3, page 8-189).
Is the problem repaired?
Troubleshooting
complete.
Replace the
MCU PWB
(REP 18.12,
page 8-202).
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
