Xerox PHASER 7500 Service Manual

4-12 Phaser 7500 Printer Service Manual
General Troubleshooting
5. Remove and reseat the Configuration Card (REP 1.5, page 8-15).
6. Remove and reseat the Image Processor Board (REP 35.1, page 8-220).
7. Try printing one of the prints from Diagnostics.
8. Replace individually, in order of priority:
• Configuration Card (REP 1.5, page 8-15).
• Image Processor Board EEPROM (PL35.1.12) (REP 35.1, page 8-220)
• Image Processor Board (REP 35.1, page 8-220)
9. Corrupt NVRAM on the Engine Control Board (MCU) can cause the printer to
continually reboot. As a last step, try replacing the Engine Control Board (REP
18.12, page 8-202).

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
