4-14 Phaser 7500 Printer Service Manual
General Troubleshooting
9 Is the voltage between the Main
Power Switch P60 and P58 110V/
220V?
Replace the
Power Switch
Kit
(PL18.1.24).
Go to step 10.
10 Unplug the Power Cord and
disconnect J4 on the Main LVPS.
Check these connections.
■ Power Switch P60 <=> Main LVPS
J4-4
■ Power Switch P58 <=> Main LVPS
J4-6
Are they normal, without any open
circuit, poor contact, and etc.?
Replace the
Main LVPS
(page 8-194).
Repair the open
circuit and poor
contact.
Troubleshooting Procedure Table (Continued)
To Next Page
