Phaser 7500 Printer Service Manual 5-3
Print-Quality Troubleshooting
LED Print Head
• IQ-1 1mm Stripes
• IQ-2 Image Shift in Process Direction
•IQ-3 White Stripes
• IQ-4 SLED Transfer Cycle Stripes
• IQ-5 In/ Out Density Difference
•IQ-6 Video Data/ Crosstalk
• IQ-7 Image Shift in Process
• IQ-8 Edge-less Image (No Margins)
• IQ-9 Contamination Stripes
• IQ-10 Chip/ Half Chip Blanks
•IQ-11 SLED Transfer Failure
