5-38 Phaser 7500 Printer Service Manual
Print-Quality Troubleshooting
3 Is +5 VDC present at P/J 401 pin 5? Replace the
Motor Drive
PWB
(REP 18.13,
page 8-204).
Replace the
LVPS
(REP 18.7,
page 8-194).
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
