Phaser 7500 Printer Service Manual 8-17

Service Parts Disassembly

3. Disconnect the wiring harness connectors.

4. Release the 4 clips that secure the Hard Disk Drive.

5. Lift the Hard Disk Drive straight up.

s7500-461
