Phaser 7500 Printer Service Manual 9-15
Parts List
Parts List 3.1 Drive (1 of 3)
Item Description Part Number
1 Fuser Input Bracket Assembly (items 2-5) (REP 3.1, page 8-26) 068K64901
2 Helical Gear (26T)
3Fuser Shaft
4 Fuser Input Bracket
5 Helical Gear (25T)
6 Spring - Fuser 809E74960
7Link - Fuser (REP 3.2, page 8-27) 012E15930
8 Spring - Link 809E74950
9 -----
10 Fuser Drive Motor Assembly (items 11, 12) (REP 3.3, page 8-28) 007K98080
11 Fuser Drive Motor
12 Gear Bracket Assembly
13 Bearing
14 Bearing
