Phaser 7500 Printer Service Manual 9-23

Parts List

Parts List 4.2 NOHAD (2 of 3)

Item Description Part Number

1 IBT Duct Assembly (items 2-9)

2Seal

3Clamp

4 Wire Harness

5 Connector

6Seal

7IBT Duct

8 IBT Fan 1/2 927W00314

9Screw

10 Plate F

11 Connector

12 Duct P2

13 P2 Fan 927W00214
