Phaser 7500 Printer Service Manual 9-27
Parts List
Parts List 5.1 Development (1 of 2)
Item Description Part Number
1 Toner Cartridge (K) Refer to “Xerox
Supplies and
Accessories” on
page 9-114
2 Toner Cartridge (C)
3 Toner Cartridge (M)
4 Toner Cartridge (Y)
5 Toner Dispense Motor Assembly (items 6-8) (REP 5.1, page 8-43) 127K57131
6 Dispense Assembly
7 Toner Dispense Motor (K, C, M, Y) (REP 5.2, page 8-45)
8 Toner CRUM Coupler Assembly (K, C, M, Y)
9 Dispenser Pipe Assembly (Y, M, C) (items 10-15) (REP 5.3, page 8-46) 094K92391
10 Guide Assembly (Y, M, C)
11 Auger Gear (Y, M, C)
12 Spring
13 Dispenser Pipe (Y) (REP 5.7, page 8-54) 052K96800
14 Dispenser Pipe (M) (REP 5.7, page 8-54) 052K96810
15 Dispenser Pipe (C) (REP 5.7, page 8-54) 052K96820
16 Dispenser Pipe Assembly (K) (items 17-19) (REP 5.3, page 8-46) 094K92600
17 Guide Assembly (K)
18 Dispenser Pipe (K) (REP 5.7, page 8-54)
19 Auger Gear (K)
