Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 9-29
Parts List
Parts List 5.2 Development (2 of 2)
Item Description Part Number
1 Deve Plate Assembly (REP 5.4, page 8-49) 015K77960
2 Developer Housing Assembly (K, C, M, Y) (items 3-5) (REP 5.5, page 8-50)
3 Housing Assembly (included with items 20-23)
4 ATC Sensor Assembly (K, C, M, Y) (included with items 20-23)
5Seal (P/O item 2)
6 Developer (K) See item 20
7 Developer (C) See item 21
8 Developer (M) See item 22
9 Developer (Y) See item 23
10 Base Plate Assembly (items 11, 15, 16) 815K02610
11 NOHAD Thermistor Assembly (items 12-14) 130K71990
12 Thermo Sensor
13 Bracket
14 Connector
15 Plate (CK)
16 Plate (YM)
17 Plunger Assembly 010K91700
18 ATC PWB (REP 5.6, page 8-52) 960K36700
19 Bracket
20 Developer Unit Kit (K) (items 2, 6) 604K48823
21 Developer Unit Kit (C) (items 2, 7) 604K48853
22 Developer Unit Kit (M) (items 2, 8) 604K48843
23 Developer Unit Kit (Y) (items 2, 9) 604K48833
24 Maintenance Kit - 480K (items 20-23, PL 6.1 - item 10, page 9-31) 604K47510
25 Plate
26 HV Cover

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
