Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 9-41
Parts List
Parts List 8.2 Xerographic (2 of 2)
Item Description Part Number
1 Bottle Guide Assembly (REP 8.4, page 8-73)
2Sensor Bracket
3 Waste Toner Bottle Full Sensor (REP 8.5, page 8-74)
4 Waste Toner Bottle Position Sensor (REP 8.5, page 8-74)
5 Waste Toner Pipe Assembly (REP 8.6, page 8-75) 052K97012
6 Agitator Motor Assembly (items 7, 8) (REP 8.7, page 8-76) 068K59500
7 Agitator Motor (REP 8.8, page 8-77)
8Gear Bracket Assembly
9 Gear Bracket Assembly (REP 8.9, page 8-78)
10 Helical Gear (29T)
11 Helical Gear (31T)
12 Drive Shaft Assembly (REP 8.10, page 8-79)
13 Helical Gear (20T)
14 Sensor Bracket Assembly (items 15, 16) (REP 8.11, page 8-80) 068K58211
15 Harness Holder
16 Auger Lock Sensor (REP 8.12, page 8-81)
17 Sleeve Bearing 413W11660
18 Wire Harness (Toner Full)
19 Waste Cartridge (REP 1.3, page 8-12) 108R00865
Waste Cartridge (REP 1.3, page 8-12) (Dell 7130) 077E00060
99 Kit Pipe Drive (includes items 9-13) 675K82370
