Phaser 7500 Printer Service Manual 9-43
Parts List
Parts List 9.1 Tray 2 Feeder/ Tray 2
Item Description Part Number
1Slide Lock Block
2Stopper
3Roller
4Roller
5 Tray 2 Assembly (PL 9.2, page 9-45) (included in item 12)
6 Tray 2 Paper Size Sensor (REP 9.1, page 8-82) 110K12100
7Switch Bracket
8 No 2 Tray Label
9 Label (Instruction)
10 Side Size Label
11 End Size Label
12 Tray 2 Kit (items 1, 5, 8-11) 675K82281
Tray 2 Kit (items 1, 5, 8-11) (Dell 7130) 675K86560
To Next Page
