Xerox PHASER 7500 Service Manual

9-50 Phaser 7500 Printer Service Manual
Parts List
Parts List 9.5 Tray 2 Feeder Assembly (2 of 2)
Item Description Part Number
1 Frame Assembly
2 Feed Roller Kit with Instructions (items 2-4) (REP 9.14, page 8-87) 675K82240
Feed Roller Kit with Instructions (items 2-4) (REP 9.14, page 8-87) (Dell 7130) 675K86570
3 Nudger Roll (REP 9.14, page 8-87)
4 Retard Roll (REP 9.14, page 8-87)
5Holder
6Lever
7Feed In Chute
8Feed Shaft
9Bearing (6)
10 Sleeve Bearing
11 Helical Gear (30T)
12 Nudger Support
13 Spur Gear (29T)
14 Clutch Assembly (25T) (REP 9.15, page 8-88)
15 Oneway Clutch (REP 9.15, page 8-88)
16 Nudger Shaft
17 Gear (25T)
18 Retard Support
19 Friction Clutch (REP 9.15, page 8-88)
20 Spacer
21 Retard Shaft
22 Retard Bearing
23 Spring
24 Spring
25 Spring
