Xerox PHASER 7500 Service Manual

9-56 Phaser 7500 Printer Service Manual
Parts List
Parts List 10.3 Tray 3/4/5 Feeder Assembly (1 of 2)
Item Description Part Number
1 Upper Frame Assembly
2Drive Bracket Assembly
3 Tray 3/4/5 Feed/ Lift Up Motor (REP 10.3, page 8-93)
4Rail
5Chute
6 Tray 3/4/5 Nudger Level Sensor (REP 10.5, page 8-94) 930W00111
Tray 3/4/5 No Paper Sensor (REP 10.5, page 8-95) 930W00111
7Actuator
8 Upper Harness Holder
9 Rear Harness Holder
10 Gear (31T)
11 Spacer
12 Bearing
13 Drive Shaft
14 Gear (13T)
15 One way Clutch
16 One Way Gear (Alternate)
17 Helical Gear (25T)
18 Helical Gear (29T/19T)
19 Washer
20 Harness Assembly (Motor1)
21 Harness Assembly (Sensor1)
22 Spring
23 Roller Assembly (PL 10.4, page 9-58)
