9-62 Phaser 7500 Printer Service Manual
Parts List
Parts List 10.11 Roller
Item Description Part Number
1Cover
2 Tray Module L/H Cover Switch (REP 10.12, page 8-100) 110E12220
3 Harness Assembly Interlock (TM SW) 962K59480
4 Chute Assembly (items 5-9) (REP 10.13, page 8-101) 054K34143
5Chute
6 Tray 4 Feed Out Sensor (REP 10.13, page 8-101) 930W00111
Tray 5 Feed Out Sensor (REP 10.13, page 8-101) 930W00111
7Actuator
8Spring
9 Wire Harness (FO)
10 Sensor Guide
11 Tray 3 Feed Out Sensor (REP 10.14, page 8-102) 130K64121
12 Chute
13 T/A Roll 4/5 (REP 10.15, page 8-103) 059K54382
14 Sleeve Bearing
15 Clamp
16 T/A Roll 3 (REP 10.15, page 8-103) 059K54382
