9-66 Phaser 7500 Printer Service Manual
Parts List
Parts List 10.13 Cover
Item Description Part Number
1 Adjuster Foot Assembly 017K94590
2 Top Cover (REP 10.20, page 8-108) 848E12720
3 Foot Cover (REP 10.20, page 8-108) 848E12730
4 Left Cover (REP 10.21, page 8-109) 848E12691
5 Right Cover (REP 10.22, page 8-110) 848E12702
6 Docking Screw 826E31691
7Joint Bracket
8Caster Assembly (S)
9Caster Assembly
10 Screw
11 Rear Cover Assembly (items 12, 13) (REP 10.19, page 8-107) 848K11191
12 Rear Cover
13 Blind Cover
14 Label
