9-68 Phaser 7500 Printer Service Manual
Parts List
Parts List 11.1 Tray Module (1T)
Item Description Part Number
1 Docking Bracket 868E06290
2Docking Screw
3 Tray 3 Assembly-STM See item 16
4 Tray 3 Feeder Assembly-STM (REP 11.1, page 8-112) 059K55532
5Feed Out Chute
6Sensor Cover
7Stopper
8Roller
9Roller
10 Label (Instruction)
11 Tray 3 Label
12 Side Size Label
13 End Size Label
14 Tray 3 Paper Size Sensor 110K12100
15 Slide Lock Block
16 Tray 3 Kit-STM (items 3, 10-13, 15) 604K52880
99 One Tray Module Option Complete 050K68710
One Tray Module Option Complete (Dell 7130) 059K76380
