Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 9-71
Parts List
Parts List 11.6 L/H Cover Assembly, Roller
Item Description Part Number
1Bracket Assembly
2Sensor Guide
3 Tray 3 Feed Out Sensor (REP 11.11, page 8-121) 130K64121
4Chute
5 STM L/H Cover Assembly Interlock Switch (REP 11.15, page 8-125) 848K07080
6 L/H Cover Assembly-STM (items 7-15) (REP 11.12, page 8-122) 848K07102
7L/H Cover-STM
8Shaft Pinch
9Handle
10 Latch (REP 11.13, page 8-123)
11 Hook
12 Spring
13 Pinch Spring
14 Pinch Bearing
15 Pinch Roll
16 STM T/A Roll Assembly (REP 11.14, page 8-124)
17 Sleeve Bearing
18 Bracket

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
