Phaser 7500 Printer Service Manual 9-79
Parts List
Parts List 13.3 Tray 1 (MPT) (3 of 5)
Item Description Part Number
1Pinch Chute Assembly
2Support Gear
3Gear (21T)
4Gear (23T)
5Lock Stopper
6Nudger Support
7Nudger Shaft
8Gear (25T)
9Stopper
10 Feed Shaft
11 Bearing
12 Sleeve Bearing
13 Gear (30T)
14 Oneway Clutch (22T)
15 Oneway Clutch
16 Spring
17 Feed Roll (REP 13.6, page 8-135) (P/O Feed Roller Kit) 675K82240
Nudger Roll (REP 13.6, page 8-135)
18 Guide
19 Pinch Spring
20 Spacer
21 Shaft
22 Pinch Roll
