Phaser 7500 Printer Service Manual 9-81
Parts List
Parts List 13.4 Tray 1 (MPT) (4 of 5)
Item Description Part Number
1MPT Lower Frame
2 Wire Harness (MPT)
3Retard Support
4Shaft
5 Friction Clutch
6Spacer
7 Retard Roll (REP 13.6, page 8-135) (P/O Feed Roller Kit) 675K82240
8Retard Spring
9Plate
10 Drive Roll Assembly (REP 13.7, page 8-136)
11 Collar
12 Gear (23T)
13 Sleeve Bearing
14 Sleeve Bearing
15 Sensor Plate
16 MPT Feed Out Sensor (REP 13.8, page 8-137) 130K72110
17 MPT No Paper Sensor (REP 13.4, page 8-133) 930W00111
18 Bottom Pad
19 Front Chute
