Phaser 7500 Printer Service Manual 9-83
Parts List
Parts List 13.5 Tray 1 (MPT) (5 of 5)
Item Description Part Number
1MPT Tray
2Front Rack
3Rear Rack
4 MPT Paper Size Sensor (REP 13.10)
5Pinion Gear
6Front Side Guide
7Rear Side Guide
8 Wire Harness (MPT FG)
9 Wire Harness (MPT Tray)
10 Plate
11 Extension Tray (L1) (REP 13.11)
12 Extension Tray (L2) (REP 13.11)
13 Sensor Link
14 Sensor Spring
