Phaser 7500 Printer Service Manual 9-87
Parts List
Parts List 14.2 L/H Cover (2 of 2)
Item Description Part Number
12nd BTR Assembly (REP 14.2, page 8-147) 059K53654
2nd BTR Assembly (REP 14.2, page 8-147) (Dell 7130) 675K87740
2 L/H Cover Assembly (items 3-13) (REP 14.3, page 8-148) 848K26801
3 Pinch Chute Assembly (items 4-10) (REP 14.4, page 8-149) 054K35151
4Pinch Chute Assembly
5Pinch Roller Assembly
6Pulley
7Spring
8 Transparency Reflector
9Holder
10 Cap
11 L/H Cover Assembly (PL 14.3, page 9-89)
12 L/H Cover
13 L/H Blind Cover (REP 14.6, page 8-151)
