Phaser 7500 Printer Service Manual 9-91
Parts List
Parts List 14.4 L/H Cover Assembly (2 of 2)
Item Description Part Number
1Harness Holder
2Harness Holder
3 Frame Assembly
4Retract Shaft Assembly (REP 14.8, page 8-153)
5 Conductor Assembly
6 Conductor Assembly
7 2nd BTR Contact Retract Sensor (REP 14.9, page 8-156) 930W00111
8 2nd BTR Contact Retract Motor Assembly (items 9-14) (REP 14.10, page 8-158) 127K52251
9Damper
10 2nd BTR Contact Retract Motor (REP 14.10, page 8-158)
11 Gear (19T)
12 Shoulder Screw
13 Bracket
14 Motor Housing Assembly
15 Sensor Holder
16 POB Sensor (REP 14.11, page 8-160) 130K87770
17 Wire Harness (LH Cover)
18 2nd Link Assembly
19 Sleeve Bearing
20 Shaft
